SPESIFIKASI
| A | General | |
|---|---|---|
| 1 | Visual Test | Yes |
| 2 | Resistance measurement of PE conductor I = 200 mA | 0.01…19.99 Ω |
| 3 | Resistance measurement of PE conductor I = 10 A | 0.01…1.99 Ω |
| 4 | Insulation resistance measurement U = 250 V | 0.25…99.9 M |
| 5 | nsulation resistance measurement U = 500 V | 0.50…99.9 MΩ |
| 6 | IEC cord test | Yes |
| 7 | PRCD test (tripping time) | 10 mA, 30 mA |
| 8 | Built-in memory for results / transmission to computer | Yes |
| 9 | Wi-Fi | Yes |
| 10 | Compatible with printer | Yes |
| 11 | Meter configuration from computer | Yes |
| 12 | Power supply | Network power supply: 20 V; 230 V; 240 V 50/60 Hz,Built-in rechargeable battery |
| 13 | Measurement category | CAT II 300 V |
| 14 | Weight | ca. 1.40 kg |
| 15 | Dimensions | 200 x 180 x 77 mm |
| 16 | Inggress protecion | IP40 |
| B | Capabilities | |
|---|---|---|
| 1 | LED test results indication | |
| 2 | Quick access to the measurement procedures | |
| 3 | Automatic measurement range selection | |
| 4 | Measurement of equivalent, touch and differential leakage current | |
| 5 | Saving results to the memory | |
The PAT-10 meter is an innovative combination of small dimensions (and the associated full mobility) with advanced measuring systems, allowing fully automatic measurements of electrical equipment, IEC cables and extension cords – also those with PRCD.
